Description
| GP1245 (12V16W) | |||||
| |||||
| Download : |
 Specification |
| Cells Per Unit | 6 |
| Voltage Per Unit | 12 V |
| Capacity | 16W@15Min-rate to 1.67V per cell @ 25°C (77°F) |
| Weight (kg) | Approx. 1.34kg. (2.95lbs.) |
| Maximum Discharge current (A) | 60A/90A (5sec.) |
| Internal Resistance Approx. | Approx. 29.8mΩ |
| Operating Temperature Range | Discharge：-15℃~50℃(5°F~122°F) Charge：-15℃~40℃(5°F~104°F) Storage：-15℃~40℃(5°F~104°F) |
| Nominal Operating Temperature Range | 25°C ±3°C (77°F ± 5°F) |
| Float charging voltage | 13.5 to 13.8 VDC/unit Average at 25°C (77°F) |
| Recommended Maximum Charging current limit | 1.60A |
| Equalization and Cycle Service | 14.4 to 15.0 VDC/unit Average at 25°C (77°F) |
| Self Discharge | Less than 10% after 90days, can be stored up to 6 months at 25°C (77°F); Fully recharging is required before usage, and charged sooner if stored at higher temperature than 25°C (77°F). |
| Terminal | F1/F2-Faston Tab187/250 |
| Container Material | ABS(UL94-HB) & Flam retardant (UL94-V0) available upon request. |
