Description
Cells Per Unit 6
Voltage Per Unit 12 V
Capacity 12 Ah @ 20hr-rate to 1.75V per cell @ 25°C (77°F)
Weight (kg) Approx. 3.67kg. (8.09 lbs.)
Maximum Discharge current (A) 150/180A (5sec.)
Internal Resistance Approx. Approx. 16.7 mΩ
Operating Temperature Range Discharge：-15℃~50℃(5°F~122°F)
Charge：-15℃~40℃(5°F~104°F)
Storage：-15℃~40℃(5°F~104°F)
Nominal Operating Temperature Range 25°C ± 3°C (77°F ± 5°F)
Float charging voltage 13.5 to 13.8 VDC/unit Average at 25°C (77°F)
Recommended Maximum Charging current limit 3.6 A
Equalization and Cycle Service 14.4 to 15.0 VDC/unit Average at 25°C (77°F)
Self Discharge It should be more than 75% of the capacity that before storage after stocked for 6 months at ambient temp. 25℃
Terminal F1/F2-Faston Tab187/250
Container Material ABS(UL94-HB) & Flammability resistance of(UL94-V0) can be available upon request.
