Description
| GP12650 | |||||
_x000D_
_x000D_ _x000D_ |
|||||
_x000D_
| Download : | _x000D_ |
_x000D_
_x000D_
 Specification |
_x000D_
| Cells Per Unit | 6 |
_x000D_
| Voltage Per Unit | 12 V |
_x000D_
| Capacity | 65 Ah @ 20hr-rate to 1.75V per cell @ 25°C (77°F) |
_x000D_
| Weight (kg) | Approx. 20.0kg. (44.08 lbs.) |
_x000D_
| Maximum Discharge current (A) | 500A (5sec.) |
_x000D_
| Internal Resistance Approx. | Approx. 5.8 mΩ |
_x000D_
| Operating Temperature Range | Discharge：-15℃~50℃(5°F~122°F)_x000D_ Charge：-15℃~40℃(5°F~104°F)_x000D_ Storage：-15℃~40℃(5°F~104°F) |
_x000D_
| Nominal Operating Temperature Range | 25°C ± 3°C (77°F ± 5°F) |
_x000D_
| Float charging voltage | 13.5 to 13.8 VDC/unit Average at 25°C (77°F) |
_x000D_
| Recommended Maximum Charging current limit | 19.5A |
_x000D_
| Equalization and Cycle Service | 14.4 to 15.0 VDC/unit Average at 25°C (77°F) |
_x000D_
| Self Discharge | It should be more than 75% of the capacity that before storage after stocked for 6 months at ambient temp. 25℃ |
_x000D_
| Terminal | B4-L terminal or Recessed Type to accept M6 nut & bolt |
_x000D_
| Container Material | Polypropylene(UL 94-HB) & Flammability resistance_x000D_ of (UL 94-V0) can be available upon request. |
