Description

Fluke 53-2-B OffersFeatures

Single input digital thermometer with data logging
Logs up to 500 points of data at user adjustable recording intervals
Measures J, K, T, E, R, S, and N-type thermocouples
Presents results in °C, °F, or Kelvin K) on a large backlit display
Provides a recall function to easily review logged data
Easy-to-access battery door that allows replacing the battery without breaking the calibration seal
Powered by three, standard AA batteries
Includes a real-time clock that captures the exact event time
Infrared USB communication port allows data to be exported to optional FlukeView Forms® Temperature PC software for further analysis and graphing
Includes an electronic offset function that compensates for thermocouple errors to maximize overall accuracy
Handles temperatures up to >1600°F 900°C)
Provides a user-friendly front panel that is easy to set up and operate
Offers sleep mode to increase battery life; 1000-hour battery life typical

Applications

Lab
QA
Process calibration
Food safety
HVAC/R Fluke 53-2-B OffersFeatures

Single input digital thermometer with data logging
Logs up to 500 points of data at user adjustable recording intervals
Measures J, K, T, E, R, S, and N-type thermocouples
Presents results in °C, °F, or Kelvin K) on a large backlit display
Provides a recall function to easily review logged data
Easy-to-access battery door that allows replacing the battery without breaking the calibration seal
Powered by three, standard AA batteries
Includes a real-time clock that captures the exact event time
Infrared USB communication port allows data to be exported to optional FlukeView Forms® Temperature PC software for further analysis and graphing
Includes an electronic offset function that compensates for thermocouple errors to maximize overall accuracy
Handles temperatures up to >1600°F 900°C)
Provides a user-friendly front panel that is easy to set up and operate
Offers sleep mode to increase battery life; 1000-hour battery life typical

Applications

Lab
QA
Process calibration
Food safety
HVAC/R

Fluke 53-2-B Specifications

Temperature Accuracy

Above -100°C
J, K, T, and E-type: ±[0.05% + 0.3°C]

R and S-type: ±[0.05% + 0.4°C]

Below -100°C
J, K, and E: ±[0.20% + 0.3°C]

T-type: ±[0.50% + 0.3°C]

Temperature

J-Type
-346 to 2192°F -210 to 1200°C)

K-Type
-328 to 2501.6°F -200 to 1372°C)

T-Type
-418 to 752°F -250 to 400°C)

E-Type
-238 to 1832°F -150 to 1000°C)

N-Type
-338 to 2372°F -200 to 1300°C)

R and S-Type
32 to 3212.6°F 0 to 1767°C)

Temperature Scale
ITS-90

Applicable Standards
NIST-175

Display Resolution
0.1°C, 0.1 K <1000 1°C, 1 K ≥1000 Environmental Specifications Operating Temperature 14 to 122°F -10 to 50°C) Storage Temperature -40 to 140°F -40 to 60°C) Humidity Without Condensation) 0 to 90%; 32 to 95°F 0 to 35°C) 0 to 70%; 32 to 122°F 0 to 50°C) Mechanical and General Specifications Batteries 3 x batteries Typical 1000-hour life Dimensions 6.8 x 3.4 x 1.5" 173 x 86 x 38 mm) Weight 0.9 lbs 400 g) Safety Specifications Overvoltage Category CSA C22.2 No. 1010.1 1992; EN 61010 Amendments 1,2 Agency Approvals CE, CSA, TÜV pending) Click here for complete specifications on the Fluke 53-2-B What's included with the Fluke 53-2-B Thermometer Holster Bead Probe Thermocouple Three-Year Warranty
