Description

Leakage current test; Current: 0-600A; voltage range: 0-600V; 50Hz-60Hz; Clamp size: 25*30mm; Auto range; RS232; Data storage: 99; Overload protection; Auto power off;
Specifications of UT251 Series High Sensitivity Leakage Current Clamp Meters

Specifications Range UT251A UT251C
Leakage current (A) 0.001mA～60A ±(1.5%+5) ±(1.5%+5)
60A～199.9A ±(2%+5)
200A～300A ±(3%+5)
300A～600A ±(4%+5)
Voltage (Freq.) 0V~600V (50Hz/60Hz) √ √
Resolution 1uA 1mA
Features
Display 4 digits LCD √ √
Clamp size 25mm x 30mm 35mm x 40mm
Auto range √ √
RS-232 √ √
Data storage 99 99
Peak/Data hold √ √
Overload protection OL √ √
Auto power off 5 minutes √ √
Low battery indication ≤7.2V ≤7.2V
Over-range display OL √ √
Test mode Clamp CT, integral mode √ √
General Characteristics
Power 9V battery (6F22)
Display 32mm x 15mm
Product color Red and grey
Product net weight 120g
Product size 175mm x 70mm x 38mm
Standard accessories Battery, RS-232 interface cable, PC software CD
Standard individual packing Gift box, carrying bag, English manual, tool box
Standard quantity per carton 6pcs
Standard carton measurement 385mm x 290mm x 115mm
Standard carton gross weight 3.3kg
