Description

• Capacity	MZ 61 ZERO TURN
  Cutting width	61 in
  Speed forward min	0 mph
  Speed forward max	8.5 mph
  Emission
  Exhaust emissions (CO₂ EU V)2	792 g/kWh
  Cutting deck
  Cutting methods	Collect/Mulch/Side discharge
  Deck thickness	11 gauge
  Deck Wash Port	No
  Greasable mandrels	Yes
  Nose roller	Yes
  Powder-coated cutting deck	Yes
  Spindle/mandrel type	Cast Aluminum
  Deck lifting system	Manual, foot assisted
  Cutting height steps	12
  Cutting deck type	11-gauge fabricated
  Anti-scalp wheels	3
  Blade engagement	Electric clutch
  Blades	3 pcs
  Cutting deck material	Steel
  Cutting height, min (approximate)	1.5 in
  Cutting height, max (approximate)	4.5 in
  Dimensions
  Weight	770 lbs
  Base machine, height (ROPS down)	42 in
  Base machine, height (ROPS up)	42 in
  Base machine, height	42 in
  Base machine, length	81 in
  Base machine, width (chute down)	74 in
  Base machine, width (chute up)	63.75 in
  Drive system
  Transmission manufacturer	Hydro-Gear
  Transmission type	Hydrostatic
  Engine
  Engine name	FR Series
  Engine Power (As rated by the engine manufacturer)1	24 hp
  Cylinder displacement	44.3 cu.inch
  Air filter type	Auto-type Paper
  Cylinders	2
  Engine cooling	Air
  Engine lubrication type	Full pressure with oil filter
  Fuel tank location	Side (Single)
  Fuel tank volume (with reserve)	5 gal (US)
  Motor/engine manufacturer	Kawasaki
  Oil filter	Yes
  Equipment
  Seat type	18″ high back
  Cup holder	Yes
  Hinged armrests	Standard
  ROPS	No
  Seat back height	High
  Seat material	Vinyl
  Control
  Connectivity	Not applicable
