Description
Product code: 060011263
Maximum power (Pmax): 60W
Voltage at Pmax (Vmp): 18.64V
Current at Pmax (Imp): 3.22A
Open-circuit voltage (Voc): 22.18V
Short-circuit current (Isc): 3.42A
Temperature coefficient of Voc: -(80±10)mV/°C
Temperature coefficient of Isc: (0.065±0.015)%/ °C
Temperature coefficient of power: -(0.5±0.05)%/ °C
NOCT (Air 20°C; Sun 0.8kW/m² wind 1m/s): 47±2°C
Operating temperature: -40°C to 85°C
Maximum system voltage: 1000V DC
Power tolerance: ± 5%
*STC: Irradiance 1000W/m², AM1.5 spectrum, module temperature 25°C
*NOCT:Nominal operating cell temperature (the data is only for reference)
Features
Nominal 12V DC for standard output.
Outstanding low-light performance.
Heavy-duty anodized frames.
High transparent low-iron,tempered glass.
Rugged design to withstand high wind pressure, hail and snow load.
Aesthetic appearance.
