Description

AC/DC voltage test : 12-690V; Phase rotation test: 50/60Hz; Continuity test; Polarity detection
Specifications of UT15B/17B/18B Max True RMS Digital Multimeters

Technical Specifications UT15B MAX UT17B MAX UT18B MAX
Certificates CE, UKCA, cETLus, REACH, RoHS
Voltage (DC) 600.0mV/6.000V/60.00V/600.0V/1000V ±(0.4%+3) ±(0.4%+3) ±(0.4%+3)
Voltage (AC) 600.0mV/6.000V/60.00V/600.0V/1000V ±(0.5%+5) ±(0.5%+5) ±(0.5%+5)
VFD (Voltage) 600.0V ±(8%) ±(8%) ±(8%)
Current (AC) 600.0µA/6000µA
/60.00mA/600.0mA/6.000A/10.00A ±(1.2%+3) ±(1.2%+3) ±(1.2%+3)
Current (DC) 600.0µA/6000µA
/60.00mA/600.0mA/6.000A/10.00A ±(1.2%+3) ±(1.2%+3) ±(1.2%+3)
Resistance 600.0Ω/6.000kΩ/60.00kΩ/600.0kΩ/6.000MΩ/60.00MΩ ±(0.5%+2) ±(0.5%+2) ±(0.5%+2)
Capacitance 6.000nF/60.00nF~600.0µF/6000µF ±(2.0%+5) ±(2.0%+5) ±(2.0%+5)
Frequency(Hz) 10Hz~10MHz ±(0.1%+3) ±(0.1%+3) ±(0.1%+3)
Duty cycle 1%~99.9% ±(1.0%+4) ±(1.0%+4) ±(1.0%+4)
Temperature(℃/℉) -55℃~500℃/–67°F~932°F – ±2℃/±4℉ ±2℃/±4℉
Main features
Display count 6000 6000 6000
Continuity / Diode √ √ √
Data hold √ √ √
MAX/MIN √ √ –
Relative mode √ √ √
Backlight (adjustable) √ √ √
Auto range/Manual range √ √ √
Auto power off √ √ √
Low battery indication √ √ √
Audible & Visual alarm √ √ √
LED test – – √
Mis-plug alarm √ √ √
Any-key wake up √ √ √
Overvoltage category CATⅢ 600V CATⅢ 600V CATⅢ 600V
General Characteristics
Power supply 2*1.5V AA 2*1.5V AA 2*1.5V AA
Product color 426U+1797C 426U+1797C 426U+1797C
Product weight 455g 455g 455g
Product dimension 182mm*91mm*45mm 182mm*91mm*45mm 182mm*91mm*45mm
Accessories 1pcs User manual, 2 pair Test lead(normal gold plated probe & Fine-tipped probe),1pcs K-type thermocouple (UT17B/UT18B MAX only), 2pcs battery, Magnetic hanger(optional)
SPQ 10 pcs 10 pcs 10 pcs
Package dimension 480×370×195mm 480×370×195mm 480×370×195mm
Standard package gross weight Around 9kg Around 9kg Around 9kg
