Description

RPM measurement: 10.0~99999RPM; Counting measurement: 0~99999 counts; Auto power off; Low battery indication; Laser-on indication;
Specifications of UT373 Mini Tachometer

Specifications Range Resolution Accuracy
RPM measurement 10.0~9999.9RPM 0.1 ±(0.04%+2)
10000~99999RPM 1
Counting measurement 0~99999 counts 1 ±1
Features
Auto range √
Auto power off √
Low battery indication √
Laser-on indication √
Data hold √
MAX/MIN √
Rotating speed/count function switching √
Overload indication √
LCD backlight √
Refresh rate 1s to 7s (>120rpm for 1s)
Sensor type Photodiode and laser tube
Target distance 50mm~200mm
Measuring angle ±30° from perpendicular
Drop test 1m
General Characterisitics
Power 1.5V battery (R03) x 3
Display 5-digit segment code; 99999 max display
Product color Red and grey
Product net weight 85g (excluding battery)
Product size 183.8mm x 56mm x 34mm
Standard accessories Batteries, reflective tape
Standard individual packing Bubble bag, gift box, English manual
Standard quantity per carton 20pcs
Standard carton measurement 272mm x 225mm x 220mm
Standard carton gross weight 3kg
