Description

• Capacity	AU/NZ SKU: 970 45 89‑01
  Cutting width	48 in
  Speed forward min	0 mph
  Speed forward max	6.5 mph
  Emission
  Exhaust emissions (CO₂ EU V)2	792 g/kWh
  Cutting deck
  Cutting methods	Collect/Mulch/Side discharge
  Deck thickness	10 gauge
  Deck Wash Port	Yes
  Greasable mandrels	Yes
  Nose roller	Yes
  Powder-coated cutting deck	Yes
  Spindle/mandrel type	Cast iron
  Deck lifting system	Manual, hand operated
  Cutting height steps	6
  Cutting deck type	ClearCut™ – Fabricated
  Anti-scalp wheels	3
  Blade engagement	Electric clutch
  Blades	3 pcs
  Cutting deck material	Steel
  Cutting height, min (approximate)	1.5 in
  Cutting height, max (approximate)	4 in
  Dimensions
  Weight	595 lbs
  Base machine, height (ROPS down)	40 in
  Base machine, height (ROPS up)	40 in
  Base machine, height	40 in
  Base machine, length	75 in
  Base machine, width (chute down)	60 in
  Base machine, width (chute up)	50 in
  Drive system
  Transmission manufacturer	Hydro-Gear
  Transmission type	Hydrostatic
  Engine
  Engine name	FR Series
  Engine Power (As rated by the engine manufacturer)1	23.1 hp
  Cylinder displacement	44.3 cu.inch
  Air filter type	Auto-type Paper
  Cylinders	2
  Engine cooling	Air
  Engine lubrication type	Full pressure with oil filter
  Fuel tank location	Side (Single)
  Fuel tank volume (with reserve)	3.5 gal (US)
  Motor/engine manufacturer	Kawasaki
  Oil filter	Yes
  Equipment
  Seat type	Comfort high back
  Cup holder	Yes
  Hinged armrests	Optional
  Hour meter type	Digital with pre-programmed service intervals
  ROPS	No
  Seat back height	High
  Seat material	Vinyl
  Control
  Connectivity	Not applicable
