Description

The BCT-468 is the ultimate handheld electrical system tester specifically designed for the heavy-duty truck market. Through the use of state of the art digital circuitry, a separable tablet and control module, and Auto Meter’s optional AMPNET cloud data management services, the BCT-468 delivers accurate, reliable, and fast testing results all-in-one new innovative Wi-Fi enabled device._x000D_
_x000D_
 _x000D_
_x000D_
Features_x000D_
_x000D_
• Innovative tablet based truck electrical system analyzer with wireless remote load module_x000D_
_x000D_
• Includes a ruggedized control module with a 8”, wide viewing angle touch screen user interface. Load module lithium-ion battery is both rechargeable and replaceable_x000D_
_x000D_
• True load test for 6 and 12 volt batteries (including AGM)_x000D_
_x000D_
• Performs battery pack testing (up to 4 batteries)_x000D_
_x000D_
• Tests 12 and 24 volt starting and charging systems_x000D_
_x000D_
• Tests 6 and 12 volt batteries rated between 100-1600 CCA_x000D_
_x000D_
• Provides a significant load during testing for incredible accuracy, even on partially discharged batteries_x000D_
_x000D_
• Provides Quick PM tests for battery pack, starter, alternator (Up to 450 Amp output), and cable voltage drop tests_x000D_
_x000D_
• Provides full electrical system test similar to the RP-129B_x000D_
_x000D_
• Delivers a clear snapshot of cranking RPM for enhanced diagnostics (patent pending)_x000D_
_x000D_
• Includes automatic voltage drop testing on starter, alternator, and lift-gate cables and connectors_x000D_
_x000D_
• Includes built in non-contact IR battery temperature measurement. Also includes port for optional inductive current probe_x000D_
_x000D_
• Wi-Fi enabled for automatic real time data collection and customer communications_x000D_
_x000D_
• Performs lift gate testing with separately sold adaptors_x000D_
_x000D_
• Field replaceable, plug and play leads for easy tool maintenance_x000D_
_x000D_
• Step by step graphical troubleshooting instructions guide user through the testing process and clear, next step advice_x000D_
_x000D_
 _x000D_
_x000D_
Operation_x000D_
_x000D_
•With the use of a microprocessor, a substantial true load, and AutoMeter’s patented digital pulse load testing protocol, the BCT-468 accurately measures the battery’s capacity and recovery for a comprehensive state of health assessment. Capable of detecting bad cells and “near end of life” conditions._x000D_
_x000D_
•The BCT-468 applies a true load to the battery in order to simulate real world operating conditions_x000D_
_x000D_
• Charging System test results measure alternator current output, voltage regulation, diode ripple, and also starter cranking RPM (patent pending).
