Description
| Specification |
_x000D_
| Cells Per Unit | 6 |
_x000D_
| Voltage Per Unit | 12 V |
_x000D_
| Capacity | 150W @15 minute-rate to 1.67V per cell @25℃ (77°F) |
_x000D_
| Weight | Approx. 11.95 kg (26.34 lbs) |
_x000D_
| Maximum Discharge Current | 225A (5sec) |
_x000D_
| Internal Resistance | Approx. 7.3 mΩ |
_x000D_
| Operating Temperature Range | Discharge：-15℃~50℃(5°F~122°F)_x000D_ Charge：-15℃~40℃(5°F~104°F)_x000D_ Storage：-15℃~40℃(5°F~104°F) |
_x000D_
| Nominal Operating Temperature Range | 25℃±3℃ (77°F±5°F) |
_x000D_
| Float Charging Voltage | 13.5 to 13.8 VDC/unit Average at 25℃ (77°F) |
_x000D_
| Recommended Maximum Charging Current Limit | 15 A |
_x000D_
| Equalization and Cycle Service | 14.4 to 15.0 VDC/Unit Average at 25℃(77°F) |
_x000D_
| Self Discharge | It should be more than 75% of the capacity that before storage after stocked for 6 months at ambient temp. 25℃ |
_x000D_
| Terminal | I2-Thread lead alloy recessed terminal to accept M6 bolt |
_x000D_
| Container Material | ABS(UL94-HB) & Flammability resistance of(UL94-V0) can be available upon request. |
