Description

Fluke 62MAXPLUS-NIST OffersThis product includes an ISO Certificate with full Data and Uncertainties.

Features

Provides a 12:1 Distance to spot ratio
Offers single laser targeting for accurate and repeatable measurements
IP54 rating against dust and moisture
High and low alarms for rapid detection of temperatures outside the limits
Powered by a single, standard AA battery
Withstands a 9.8′ 3 m) drop
Small, lightweight form factor to clip comfortably to your tool belt or belt loop, or easily fit in your tool box
A large, backlit display to make data easier to read, even in dark areas
Displays Min/Max/Avg/Dif: the minimum, maximum or average temperature, or the difference between two measurements

Applications

Non-contact temperature Fluke 62MAXPLUS-NIST OffersThis product includes an ISO Certificate with full Data and Uncertainties.

Features

Provides a 12:1 Distance to spot ratio
Offers single laser targeting for accurate and repeatable measurements
IP54 rating against dust and moisture
High and low alarms for rapid detection of temperatures outside the limits
Powered by a single, standard AA battery
Withstands a 9.8′ 3 m) drop
Small, lightweight form factor to clip comfortably to your tool belt or belt loop, or easily fit in your tool box
A large, backlit display to make data easier to read, even in dark areas
Displays Min/Max/Avg/Dif: the minimum, maximum or average temperature, or the difference between two measurements

Applications

Non-contact temperature

Fluke 62MAXPLUS-NIST Specifications

Temperature Range
-22 to 1202°F -30 to 650°C)

Accuracy
±34.7°F ±1.5°C) or ±1.5% of reading, whichever is greater

14 to 32°F -10 to 0°C): ±2.0

-22 to 14°F -30 to -10°C): ±3.0

Response Time 95%)
<500 ms 95% of reading) Spectral Response 8 to 14 microns Emissivity 0.10 to 1.00 Optical Resolution 12:1 calculated at 90% energy) Display Resolution 0.2°F 0.1°C) Repeatability of Readings ±0.8% of reading or <±2°F 1.0°C), whichever is greater Power AA Battery Battery Life 8 hours with laser and backlight on Operating Temperature 32 to 122°F 0 to 50°C) Storage Temperature -4 to 140°F -20 to 60°C), without battery Operating Humidity 10% to 90% RH non-condensing at 86°F 30°C) Operating Altitude 6561.7' 2000 m) above mean sea level Storage Altitude 39,370.08' 12,000 m) above mean seal level Drop Test 9.8' 3 m) Dimensions 6.88 x 3.34 x 2.95" 175 x 85 x 75 mm) Weight 0.56 lbs 255 g) IP Rating IP 54 per IEC 60529 Vibration and Shock IEC 68-2-6 2.5 g, 10 to 200 Hz, IEC 68-2-27, 50 g, 11 ms EMC EN 61326-1:2006 EN 61326-2:2006 Standards and Agency Approval Compliance: EN/IEC 61010-1: 2001 Laser safety: FDA and EN 60825-1 Class II Click here for complete specifications on the Fluke 62MAXPLUS-NIST What's included with the Fluke 62MAXPLUS-NIST Thermometer ISO Certificate with full Data and Uncertainties Carabiner Instruction Sheet Three-Year Warranty Fluke Infrared Thermometers: What is Distance-to-Spot Ratio? This explanatory video will go over how does distance-to-spot ratio affects the ability of an infrared thermometer to measure the temperature of a surface from a distance. Also, these devices are equipped with laser pointers. How To Configure the Laser Pointer on your Fluke 62 MAX Infrared Thermometer Using the laser pointer is easy! Press and release the green trigger and then push the SEL button multiple times until "LAS On" appears on the display. Use the SET button to turn it On or Off. Watch the video to learn the rest! Fluke: Emissivity with Polished Metals Learn how to take measurements correctly!) on polished metals as they do not radiate very efficiently. Watch this instructional to see how they test out this measurement. Introducing the Fluke 62 MAX/MAX+ Infrared Thermometer This video provides an overview of uses for the thermometer while being used in the field. It is water-resistant, drop tested to 3 meters, dust resistant and so much more!
