Description

Fluke 113 OffersFeatures

VCHEK™ LoZ low impedance measurement function to simultaneously test for voltage or continuity
True RMS for accurate AC measurements on non-linear loads
A large backlit display allows for easy visibility in low-lit areas
Record signal fluctuations using the Min/Max function
Diode test for testing general-purpose germanium, silicon, and power diodes
Integral holster with probe holders for easy storage
Auto and Manual ranging for added user functionality
Meets measurement category CAT IV 600 V and Category IV 300 V standards for a higher level of safety
The optional TPAK magnetic hanger allows the user hands-free flexibility (sold separately)Fluke 113 OffersFeatures

VCHEK™ LoZ low impedance measurement function to simultaneously test for voltage or continuity
True RMS for accurate AC measurements on non-linear loads
A large backlit display allows for easy visibility in low-lit areas
Record signal fluctuations using the Min/Max function
Diode test for testing general-purpose germanium, silicon, and power diodes
Integral holster with probe holders for easy storage
Auto and Manual ranging for added user functionality
Meets measurement category CAT IV 600 V and Category IV 300 V standards for a higher level of safety
The optional TPAK magnetic hanger allows the user hands-free flexibility (sold separately)

Fluke 113 Specifications

VCHEK

Range
6, 60, 600 V

Resolution
0.001, 0.01, 0.1 V

Accuracy
DC, 45 to 500 Hz: 2.0% + 3

500 Hz to 1 kHz: 4.0% + 3

Diode Test

Range
2 V

Resolution
0.001 V

Accuracy
2.0% + 3

Continuity

Accuracy
Beeper on <20 Ω, off >250 Ω detects opens or shorts of 500 µs or longer

Ω

Range
600 Ω, 6, 60 kΩ

Resolution
0.1 Ω, 0.001, 0.01 kΩ

Accuracy
0.9% + 2

0.9% + 1

0.9% + 1

Capacitance

Range
1000 nF, 10, 100, 9999 µF

Resolution
1 nF, 0.01 µF, 0.1 µF, 1µF

Accuracy
1.9% + 2

100 to 1000 µF: 1.9% + 2

1000 µF: 5% + 20

General Specifications

Maximum Voltage Between Any Terminal and Earth Ground
600 V

Display
3¾-digits, 6000 counts, updates 4/sec

Operating Temperature
14 to 122°F (-10 to 50°C)

Storage Temperature
-22 to 140°F (-40 to 60°C)

Temperature Coefficient
0.1 x (specified accuracy)/°C (<18 or >28°C)

Operating Altitude
6561.7′ (2000 m)

Storage Altitude
32808.4′ (10,000 m)

Relative Humidity
95% to 86°F (30°C)

75% to 104°F (40°C)

45% to 122°F (50°C)

Battery Type
9 V Alkaline, ANSI 1604A/IEC 6F22

Battery Life
Alkaline: 300 hours typical, without backlight

Shock
3.3′ (1 m) drop per IEC 61010–1–2001

Vibration
Per MIL-PRF-28800 for Class 2 instrument

Dimensions
6.58 x 33.5 x 1.81″ (167.1 x 85.1 x 46 mm)

Weight
13.0 oz (404 g)

Safety
Complies with ANSI / ISA 82.02.01 (61010–1) 2004, CAN / CSA-C22.2 No 61010-1-04, UL 61010–1 (2004) and IEC / EN 61010–1 2nd Edition for measurement Category IV, 600 V, Pollution Degree 2, EMC EN61326–1

EMI Regulations
Complies with FCC Part 15, Class B

Click here for complete specifications on the Fluke 113

What’s included with the Fluke 113
Multimeter
Test Leads
One 9 V Battery
Users Manual
