Description

• SPECIFICATIONS

  Capacity
  #Speed reverse min	0 km/h
  Speed forward max	13.7 km/h
  Speed forward min	0 km/h
  Speed reverse max	7.2 km/h
  Engine
  Air filter type	Auto-type Paper
  Battery capacity	18 Ah
  Battery type	Lead-Acid
  Battery voltage	12 V
  Cylinder displacement	726 cm³
  Cylinders	2
  Engine cooling	Air
  Engine lubrication type	Full pressure
  Engine name	FR Series
  Fuel tank location	Side (Single)
  Fuel tank volume	18.9 l
  Generator	16 A
  Motor/engine manufacturer	Kawasaki
  Motor/engine model	FR691V
  Oil capacity	2.1 l
  Oil filter	Yes
  Power output	23 hp
  Power output	17.2 kW
  Power source	Petrol
  Power/fuel type	Gasoline
  Cutting deck
  Anti-scalp wheels	3
  Blade engagement	Electric clutch
  Blade type	High-Lift blade
  Blades	3 pcs
  Blade-tip speed	93.98 m/s
  Clutch rating	122.02 Nm
  Cutting deck material	Steel
  Cutting deck type	ClearCut™ – Fabricated
  Cutting height max	114.3 mm
  Cutting height min	38.1 mm
  Cutting height steps	13
  Cutting methods	Collect/Mulch/Side discharge
  Cutting width	48 in
  Cutting width	122 cm
  Deck lifting system	Manual, foot assisted
  Deck thickness	3.4 mm
  Deck Wash Port	Yes
  Greasable mandrels	Yes
  Nose roller	Yes
  Powder-coated cutting deck	Yes
  Spindle/mandrel type	Cast iron
  Dimensions
  Base machine, height	106.7 cm
  Base machine, length	192 cm
  Base machine, width	124.5 cm
  Base machine, width (chute down)	154.9 cm
  Base machine, width (chute up)	142 cm
  Tyre size, front Diameter	6 in
  Tyre size, front Width	6.5 in
  Tyre size, rear Diameter	10 in
  Tyre size, rear Width	10 in
  Weight (complete product w/o side packed articles)	335.6 kg
  Wheel/rim size, front Diameter	13 in
  Wheel/rim size, rear Diameter	22 in
  Equipment
  Collector	Available as accessory
  Cup holder	Yes
  Headlights	No
  Hour meter type	Digital with pre-programmed service intervals
  ROPS	Yes
  Seat back height	High
  Seat material	Vinyl
  Seat spring	Yes
  Seat type	Premium High back 21″ with armrest
  Drive system
  Drive system	Rear wheel drive
  Fan-cooled pumps	Yes
  Pump displacement	10 cm³
  Transmission manufacturer	Hydro-Gear
  Transmission model	ZT 3100
  Transmission type	Hydrostatic
