Description

DC/AC voltage: 1000V; DC/AC current: 20A; Resistance: 60MΩ; Capacitance: 60mF; Frequency: 40MHz; True RMS
Specifications of UT195 Series Professional Multimeters

Specifications Range UT195E UT195M UT195DS
DC voltage (V) 1000V ±(0.5%+3) ±(0.5%+3) ±(0.5%+3)
AC+DC 750V ±(0.7%+3) ±(0.7%+3) ±(0.7%+3)
AC voltage (V) 600V ±(1.5%+4)
LoZ ACV 600V ±(2%+3) ±(2%+3) ±(2%+3)
DC current (A) 20A ±(0.8%+3) ±(0.8%+3) ±(0.8%+3)
AC current (A) 20A ±(1%+3) ±(1%+3) ±(1%+3)
Resistance (Ω) 60MΩ ±(0.8%+2) ±(0.8%+2) ±(0.8%+2)
Capacitance 60mF ±(3%+5) ±(3%+5) ±(3%+5)
Frequency 60Hz~10MHz ±(0.1%+4)
60Hz~40MHz ±(0.1%+4) ±(0.1%+4)
Duty cycle 0.1%~99.9% ±(2%+5) N/A ±(2%+5)
Temperature (°C) -40°C~1000°C ±(1.5%+4)
Temperature (°F) -40°F~1832°F ±(2%+5)
Features
Display count 6000 6000 6000
Display interface (LCD) Single Single Dual
Measurement sampling rate times/s 3 3 5
Analog bar sampling rate times/s 10 20
Analog bar 31 sections √ √
True RMS √ √ √
AC voltage frequency response 45~400Hz 45~1kHz 45~5kHz
AC current frequency response 45~400Hz 45~1kHz 45~5kHz
3-phase motor sequence test 600V √ √
Low pass filter 1kHz 3dB attenuation √
Diode/Continuity test 3.5V 3V 3V
Peak hold 250μs √
Auto/Manual range √
Continuity buzzer √
Low battery indication √
Data hold/Auto power off √
MAX/MIN √
Function selection √
Flashlight/Auto backlight √
General Characteristics
Power 9V battery
LCD size 66mm x 51mm
Product color Red and grey
Product net weight 437g
Product size 195mm x 95 mm x 58mm
Standard accessories Test probes, battery, carrying bag, point contact temperature probe (UT195M)
Standard individual packing Gift box, English manual
Standard quantity per carton 6pcs
Standard carton measurement 580mm x 375mm x 215mm
Standard carton gross weight 7.2kg
